Rahmen

ONE-SIXTY FR LITE III; 171 mm suspension travel mullet, material: aluminium, 29x2.5" max. wheelsize, 148x12 mm axle standard, BSA bottom bracket standard

Rahmengröße

S, M, L, XL

Dämpfer

DVO Jade X D3; coil, spring rate per size XSHORT and SHORT 300 lbs, MID: 350 lbs, LONG: 400 lbs, XLONG: 450 lbs

Gabel

SR Suntour Durolux 38 RC; Air, 180 mm suspension travel, Tapered, xx mm fork offset, 29x2.60" max. wheelsize

Vorderradbremse

Tektro Gemini HD-M535; 4 piston

Hinterradbremse

Tektro Gemini HD-M535; 4 piston

Schaltwerk

Shimano CUES U6000; GS

Kurbel

MERIDA Expert TR; 32 teeth, 170 mm for all sizes

Kettenführung

MERIDA EXPERT TR ISCG05

Kassette

Shimano LG300; 11-48 teeth, 10 speed

Lenker

MERIDA EXPERT TR II; material: aluminium, 780 mm width, XS/S 18 mm rise, M/L/XL 30 mm rise

Vorbau

MERIDA EXPERT eTRII; material: aluminium, 35 mm diameter, 0° stem angle, 40 mm

Steuersatz

Acros ICR MERIDA EXTERNAL neck; Upper and lower IPS sealing

SPACER

210 mm, 12.5 mm

Vorderradnarbe

Shimano TC500-B; 110x15 mm width front hub, 32 spoke holes, Centerlock

Hinterradnarbe

Shimano TC500-HM-B; 148x12 mm width rear hub, 32 spoke holes, Centerlock

Felgen

MERIDA COMP TR II; 110x15 mm width front hub, 148x12 mm width rear hub, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29", rear 27.5"

Sattel

MERIDA COMP SL; V-mount

Sattelstütze

MERIDA EXPERT TR II; 34.9 mm diameter, 0 mm setback, XS/S: 150 mm travel seatpost - M: 170 mm travel seatpost - L/XL: 200 mm travel seatpost

Schalthebel links

Shimano SL-MT500-L

Schalthebel rechts

Shimano CUES U6000

Vorderreifen

Continental Kryptotal-F; 29x2.4", fold, TR, Enduro casing, Soft Compund

Hinterreifen

Continental Kryptotal-R; 27.5x2.4", fold, TR, Enduro Casing, Soft Compound
